UV / IR Spectrum – for medium distance detection and high false alarm immnity.
Compact & lightweight design.
Lower power requirement (35mA –standby / 70mA – alarm).
Ex cable gland / 1-meter cable assembled & provided for users’ easy installation.
Specification :
- Detection Range : nom. up to 30m @ 1ft-sq n-heptane fires.
- Field of View : 90°.
- Response Time : typical 3 to 5 sec.
- Input Rating : 24VDC (11V to 32V).
- Outputs : Relay Contacts(Alarm/Fault) / 4-20mA current(stepped).
- Power Consumption : max.35mA(Stanby) / max.70mA(Alarm).
- Enclosure(optional) : Aluminium with anodizing finish.
- Dimensions / Weight : 83(D)X126(L)mm / 1.1kg.
- Certifications : ATEX approved(by DNV) /CE-marking / KFI(Korea).
Application :
- Offshore Oil & Gas Installations.
- Onshore Oil & Gas Installations and pipelines.
- Petrochemical plants.
- Chemical plants.
- Shipbuilding facility.
- Automotive industry.
- Storage tank farms.
- Power generation facility.
- Painting industry.
- Warehouse.
- Waste disposal facility.
- Explosive & Munitions.
